Pipelines with Nextflow

⏱ Estimated reading time: ~15 minutes  •  📖 Lecture companion (no coding)

🎥 This section is normally delivered as a live lecture (a video link will be added after the course). The written version below covers the same material, so you can follow along, revisit it, or catch up if you missed the talk.

What this section covers

• Part A — Why we need pipelines: reproducibility, complexity, and the pain of scaling analyses
• Part B — Nextflow: what it is and how it ties everything together
• Part C — How Nextflow works: processes, channels, workflows and parallelism
• Part D — Containers: why they matter for reproducibility
• Part E — nf-core: the community and its ready-made pipelines
• Further material: where to go next

Part A — Why do we need pipelines?

1. The reproducibility crisis

Science relies on results being reproducible — someone else should be able to take your data and methods and arrive at the same answer. Yet across many fields, a large fraction of published results cannot be reproduced. In computational biology a big part of the problem is the analysis itself: the exact software, versions, parameters and environment used are often not recorded well enough for anyone (including the original author, months later!) to repeat them.

💡 The goal of a pipeline is to capture every step of an analysis — the tools, their versions, the parameters and the order they run in — so the whole thing can be re-run and produce the same result on demand.

2. Modern bioinformatics is complex

A realistic analysis is rarely one command. An RNA-Seq experiment (like the one you’ll run in Part 3) might involve:

• quality control of raw reads (e.g. FastQC)
• trimming adapters and low-quality bases (e.g. Trim Galore)
• aligning reads to a genome (e.g. STAR)
• quantifying gene expression (e.g. Salmon/RSEM)
• summarising and reporting (e.g. MultiQC)

Each of those is a separate program, with its own inputs, outputs, options and software dependencies — often chained across dozens of steps and many samples. Running each step by hand is slow, error-prone and almost impossible to reproduce exactly.

3. The same analysis can give different results on different computers

This is the subtle one. Even with identical input data and identical commands, you can get different numerical results on different machines — because of differences in operating system, system libraries, or tool versions.

📄 Di Tommaso et al. (2017) demonstrated exactly this problem and showed that packaging tools in containers makes results consistent across systems. Di Tommaso, P., Chatzou, M., Floden, E.W. et al. “Nextflow enables reproducible computational workflows.” Nature Biotechnology 35, 316–319 (2017). https://doi.org/10.1038/nbt.3820

If “which laptop you ran it on” can change your answer, you can’t trust the answer — and neither can a reviewer.

4. Configuring for HPC and the cloud is hard

Real datasets are big, so analyses usually need to run on a High-Performance Computing (HPC) cluster or in the cloud (AWS, Google Cloud, Azure) rather than a laptop. But every HPC scheduler (SLURM, SGE, PBS…) and every cloud platform has its own way of submitting jobs, requesting memory/CPUs, and moving data. Rewriting your analysis for each environment is tedious and fragile.

5. Nextflow provides a solution

A workflow manager solves all four problems at once. It lets you describe your analysis once, then:

Nextflow is one of the most widely used workflow managers in bioinformatics — and it’s the one this course is built around.

Part B — What is Nextflow?

Nextflow is a language (and runtime) for scaffolding a series of tasks into a modern, reproducible workflow. It provides:

• automatic software management using containers (no manual installs),
• a dataflow programming model that passes data cleanly between steps, and
• a modular design, so a step written once can be reused in any pipeline.

Nextflow has several features that make it especially powerful:

• Portability — the same pipeline runs locally, on HPC, or in the cloud, just by changing configuration.
• Version control — pipelines are Git repositories, so runs are transparent and traceable.
• Testing — modules can be unit-tested (e.g. with nf-test) to catch failures early.
• Community — a large, active ecosystem building reproducible pipelines together (see nf-core).

7. How Nextflow ties it all together

The key idea is that Nextflow separates the description of your analysis from the details of running it. Your pipeline script says what should happen; Nextflow connects that to where it runs, which software it uses, and how it’s tracked:

flowchart TB
  A["📜 Your pipeline script<br/>(processes + workflow logic)"] --> B["⚙️ Nextflow runtime<br/>schedules &amp; connects tasks"]
  B --> C["🖥️ Executor<br/>local · HPC · cloud"]
  B --> D["📦 Containers<br/>Docker · Singularity · Apptainer"]
  A --> E["🔀 Version control<br/>Git / GitHub"]

Because these concerns are separated, you can move the same pipeline from your laptop to a supercomputer by changing a config file — the science stays identical.

Part C — How Nextflow works

8. Processes and channels

Nextflow is built from two core concepts:

• Processes — a single job: a script or program (with its own inputs, outputs and command). Think of a process as one step or module of the pipeline.
• Channels — the “conveyor belts” that carry data into processes and between them. Processes read from and write to channels, so Nextflow always knows how data flows.

flowchart LR
  ch1(["Channel:<br/>raw reads"]) --> P1["Process: TRIM"]
  P1 --> ch2(["Channel:<br/>trimmed reads"]) --> P2["Process: ALIGN"]
  P2 --> ch3(["Channel:<br/>BAM files"])

The structure of a process

A typical process looks like this:

process TRIM {

    input:
    path 'sample.1.fastq'

    output:
    path 'sample.1.trim.fastq'

    script:
    """
    trim_galore -o sample.1.trim.fastq sample.1.fastq
    """

}

In the process above:

• the input is a specific FASTQ file,
• the output is the trimmed FASTQ file it produces, and
• the script block (between the """ triple quotes) is the actual command that runs.

The structure of a workflow

Processes are wired together in a workflow block. The workflow decides which processes run and how the output channel of one becomes the input channel of the next:

workflow {
    reads_ch = Channel.fromPath('data/*.fastq')
    TRIM(reads_ch)
    ALIGN(TRIM.out)
}

You never tell Nextflow the exact order to run things step by step. Instead you describe how data flows, and Nextflow works out the order automatically from those connections.

9. How Nextflow parallelises the dataflow

Because data travels in channels, Nextflow can see when tasks are independent — and run them at the same time. If you feed three samples into a channel, the TRIM process runs three times in parallel (as many at once as your machine or cluster allows):

flowchart LR
  ch(["Channel:<br/>sample1 · sample2 · sample3"]) --> P1["TRIM sample1"]
  ch --> P2["TRIM sample2"]
  ch --> P3["TRIM sample3"]
  P1 --> out(["trimmed reads"])
  P2 --> out
  P3 --> out

This is the big win of the dataflow model: you write the logic once for a single sample, and Nextflow scales it out across all your samples and all your available compute — no extra code required.

Part D — Why use containers?

10. Containers make software reproducible

A container bundles a program together with everything it needs to run — its exact version, its libraries, and its operating-system dependencies — into a single portable package (e.g. Docker, Singularity, or Apptainer).

This is what solves problem #3 from Part A: instead of relying on whatever version of a tool happens to be installed on a given machine, Nextflow pulls the same container every time, so:

• you don’t have to install any of the underlying tools yourself,
• everyone runs byte-for-byte the same software, and
• results are consistent across your laptop, an HPC cluster and the cloud.

🧪 In Part 3 you’ll use -profile docker, which tells Nextflow to run every step inside its container. That single flag is why you don’t need to install FastQC, STAR, Salmon and the rest by hand.

Part E — The nf-core community

11. What is nf-core?

nf-core is a community effort to build gold-standard, reproducible Nextflow pipelines. Rather than everyone writing their own RNA-Seq or variant-calling pipeline from scratch, nf-core provides curated, peer-reviewed, well-tested and thoroughly documented pipelines that have become an industry standard.

Highlights of the nf-core ecosystem:

• A catalogue of ready-to-run pipelines covering many common analyses — RNA-Seq, variant calling, single-cell, metagenomics, and many more.
• Consistency — every pipeline follows the same conventions, so once you can run one, you can run them all.
• Built-in best practice — containers, testing, versioning and documentation come as standard.
• A welcoming community — join them on Slack.

In Part 3 you’ll run the real nf-core/rnaseq pipeline on example data — putting everything in this lecture into practice.

Further material

If you’d like to go deeper (highly recommended if you want to write your own pipelines):
